Multi-functional display version 2.00.330 radar user manual/Руководство пользователя радара с многофункциональным дисплеем версии 2.00.330

Издание на английском языке
The book provides a complete guide to the operation and configuration of the Navi-Radar radar system. It covers all aspects, from turning on and initially configuring the radar to managing navigation information and target processing. Readers will learn how to configure the interface, manage data display, use different display modes, and process information about moving objects. The book also includes tips on working with maps and routes, as well as recommendations for improving navigation safety. It is designed to help users make the most of the radar system's capabilities.

См. также Radar Quick Reference

Contents
Table of Contents
Printing House Conventions
List of Documents
Preamble
Annotation
List of Abbreviations
Attention
Chapter 1. RADAR User Interface
Radar User Interface Structure
Control Panel
Keyboard
Virtual Keyboard
Chapter 2. Turning Radar On/Off and Initial Setup
Turning NR On
Operation Checking
Initial RadarSetup
Selecting Radar Picture
Setting Outgoing Pulse Length
Radar Receiver Tuning
Adjusting Video Signal
Adjusting Display Brilliance
Radar Setup in the Absence of Targets for 25 kW SRT and 30 kW Scanner
Radar Setup in the Absence of Targets for 10 kW Scanner.
Turning on HCS Mode for 12 KW SRT Scanner
Transfer of Scanner Control Rights
Turning NR Off
Chapter 3. Handling Radar
Obtaining of Navigational Information in the RadarTask
Own Ship Coordinates and Motion Parameters
Navigational Status, CCRP and Cursor Position
Scanner Control
Parallel Index
Display Adjustment
Setting Overlay Colour
Setting Screen Colour Palette
Setting Screen Graphic Presentation
Selecting Own Ship Symbol and Cursor Display Mode
Adjustment of Plan Position Indicator
Setting Range Scale
Setting Motion Mode
Setting Radar Picture Orientation
Setting PPI Off-Centring
Use of Ahead Function
Ahead Function Adjustment
Relative Motion Mode
True Motion Mode
Use of Show Radar Function
Handling RADAR Task Configurations
Using Local User Configuration
Creating Local User Configuration
Loading Local User Configuration
RADAR Deleting Local User Configuration
Using Bridge User Configuration
Creating Bridge User Configuration
Deleting Bridge User Configuration
Use of NR Tools
Setting Fixed Range Rings
EBL/VRM
Turning on EBL/VRM
EBL/VRM Control
Setting EBL and VRM Values via ES6 Keyboard
Setting EBL and VRM Values in EBL-VRM Window
Setting EBL and VRM Values with the Cursor
EBL/VRM Offset Adjustment
Shifting EBL/VRM
Turning off EBL/VRM
Index Lines
Turning on Display of Index Lines
Control of Index Line Positions
Setting Values of Index Line Positions in Index Lines Panel
Setting Index Lines with the Cursor
Turning Off Display of Index Lines
Setting of Sensors
Setting Position Sensors
Setting COG/SOG Sources
Using GOG/SOG Data from the Position Sensor
Using GOG/SOG Data from DLOG
To Use STW Drift Taken into Account
Using GOG/SOG Data Obtained with the Aid of Reference Points
Setting Reference Points
Cancelling Reference Point
Using GOG/SOG Data Obtained with the Aid of Reference Points
Setting Heading Source
Setting STW Source
Using Speed from DLOG
Using Speed from LOG
Entering STW Manually
Transfer of Navigation Rights
Setting Stabilisation Modes
Setting Video Signal Accumulation Level
Turning On Interference Rejection
Turning On the Enhanced Video Mode
Adjustment and Turning оn the Combining Radar Overlay Mode
Handling Echo Trails
Radar Maps
Handling Radar Maps if ECDIS Task Available
Handling Radar Maps in Standalone Configuration
Creating and Saving Radar Maps
Plotting Point Type Objects
Plotting Line and Area Type Objects
Plotting Route
Saving Radar Map
Loading and Unloading Radar Maps
Shifting and Deleting Radar Map Objects
Shifting Radar Map Objects
Deleting Radar Map Objects
Deleting Radar Maps
Handling Routes
Loading Route in Standalone Configuration
Obtaining Information about Monitored Route
Turning On Route Display
SART Operation Using RADAR Task
Chapter 4. Handling Targets
General
Handling Pre-Calculated Motion Vectors
Work with Targets'Tracks
Calling Target Data Card
Turning On Display of Target Numbers
Setting Safety Parameters in Target Tracking
Turning On Mode of Associating AIS and ARPAT argets
Filtering Lost Targets
Handling Ring Shaped Guard Zones
Turning On Ring Shaped Guard Zones
Setting Guard Zone Limits
Turning Off Guard Zones
Trial Manoeuvre
SimulatorARPATargets
Setting Training Targets
Editing Simulator Target Motion Vectors
Deleting Simulator Targets
Test Scenario for the Simulator
Using the Curved Heading Line
Using the Predictor
Handling ARPATargets
Turning On/OffARPA Information Display
Manual Acquisition of Targets for Tracking
Cancelling Tracked Targets Manually
Cancelling All Tracked Targets in PPI Area
Handling AIS Targets
Turning On/Off AIS Information Display
Turning On/Off AIS Target Vectors
Display of AIS Target Identifiers
Viewing Current Data of Own AIS Transmitter
Filtering AIS Targets
Sleeping AIS Targets Handling
Turning On DR Mode for AIS Targets
Chapter 5. Handling Chart
Turning On Chart Display
Chart Selection
Turning On Display of Different Chart Objects
Adjusting Chart Brilliance
Selection of Chart Data Display
Turning On ENC Display on Top of Radar Picture
Obtaining Information on Vector Charts and Chart Objects
Turning Off Chart Display
