Multif-unctional display Version 2.00.330 Radar Quick Reference/Многофункциональный дисплей. Версия 2.00.330. Краткий справочник по радару

Издание на английском языке
The book is a guide to using and configuring a multifunction display for radars. It describes the main functions of the device, including controlling display modes, tracking targets, range and sensitivity settings, and setting alarms to ensure safety on the water. The book helps users to use navigation technologies effectively and improve navigation safety.

См. также Radar user manual

Contents
Purpose
Running Navi-Radar Task
Turning NR Off
ES6 Keyboard.
RADAR User Interface
"Multipanel" Window
Setting up the Display
Adjusting Video Signal
Radar Receiver Tuning
Reading of Own Ship Coordinates and Motion Parameters
Change Range Scale
Setting of Sensors
Setting Position Sensors
Settings COG/SOG Sources
To Use STW Drift Taken into Account
Using GOG/SOG Data from DLOG
Using GOG/SOG Data from the Position Sensor
Using GOG/SOG Data Obtained with the Aid of Reference Points
Setting Heading Source.
Setting STW Source
Entering STW Manually
Transfer of Navigation Rights
Using Speed from DLOG
Using Speed from LOG
Evaluation and Acknowlegement of Alarms.
Evaluation of Range and Bearing to Objects.
Evaluation of Range and Bearing to Objects from Own Ship
EBL/VRM Control
Turning On EBL/VRM
Evaluation of Range and Bearing to Objects Between Two Objects
Targets Acquisition
Selection of Radar Targets for Tracking
Turning On/Off AIS Target Vectors
Calling Target Data Card
Handling Pre-Calculated Motion Vectors
Working with Parallel Index Lines
Turning On Display of Index Lines
Control of Index Line Positions.
Setting Index Lines with the Cursor
Setting Values of Index Line Positions in Index Lines Panel
Turning Off Display of Index Lines
Working with Trial Manoeuvre
Abbreviations Used in the User Inteface
