Colonial Schooner Port Jackson 1803. Building Instructions/Колониальная шхуна Порт-Джексон 1803. Инструкция по сборке

Издание на английском языке
This book presents a collection of wooden models of Australian colonial ships created by Modeller's Shipyard, the only manufacturer of such models in Australia.
Масштаб модели 1:50
L=590 мм
H=450 мм

Content
1.0. Introduction
2.0. Historical Notes
3.0. General Instructions
4.0. Parts List (Modeller’s Shipyard reserves the right to make changes to the instructions, components &/or kit contents at any time without notice)
5.0. Laser Cut Boards
6.0. Hull Construction
6.1. Keel and Bulkheads
6.1.2. Square the Frames to the Keel
6.1.3. Fit the Bow Blocks
6.1.4. Fit False Deck
6.1.5. Transom
6.1.6. Fairing the Frames
6.1.7. Deadwood Area
6.2. Hull Planking - First Layer
6.2.1. Starting the First Layer of Planking
6.2.2. Completing the first layer of planking
6.2.3. Bulwark
6.2.4. Second Layer of Hull Planking
6.2.5. Fitting Stem Post, Stern Post & False Keel
6.3. Deck Planking
6.4. Finishing the Hull
6.4.1. Cap Rails
6.4.2. Hawse Holes & Bolsters
6.4.3. Mast Heels
6.5. Deck Fittings & Furniture
6.5.1. Head Timber A
6.5.2. Head Timber B
6.5.3. Bowsprit Stock
6.5.4. Catheads
6.5.5. Bitt Heads
6.5.6. Windlass
6.5.7. Hatch
6.5.8. Barrel & Base
6.5.9. Cargo Hatch
6.5.10. Pump
6.5.11. Capstan
6.5.12. Companionway
6.5.13. Boom Supports
6.5.14. Rail Stanchions
6.5.15. Quarter Rails
6.5.16. Boom Sheet Traveller
6.5.17. Rudder and Tiller
6.5.18. Channels
6.5.19. Anchors
6.5.20. Anchor Cranes
7.0. Masts, Yards, Gaffs & Boom
7.1. Main Mast
7.2. Foremast
7.3. Yards, Gaffs and Boom
7.4. Bowsprit and Jib Boom
7.5. Masts & Bowsprit
7.6. Deadeye Straps
7.7. Shroud Extension Angle
8.0. Rigging
8.1. Types of Rigging
8.2. Preparation for Rigging
8.3. Standing Rigging
8.4. Shrouds
8.4.1. Shrouds - Lower Main & Foremast
8.4.2. Shrouds - Upper Main & Foremast
8.4.3. Lanyards
8.4.4. Ratlines
8.5. Belaying Plan
8.6. Tackles
8.7. Bowsprit Shrouds
8.8. Jib Boom Shrouds
8.9. Footrope
8.10. Gammoning
8.11. Bobstay
8.12. Stays - Foremast
8.14. Mainstay
8.13. Main Topmast Stay
8.14. Mainstay
8.15. Backstay Straps
8.16. Main Topmast Backstay
8.17. Fore Topmast Backstay
8.5. Running Rigging
8.5.1. Main Gaff Throat Halliard
8.5.2. Main Peak Halliard
8.5.3. Flag Line
8.5.4. Fore Gaff Throat Halliard
8.5.5. Fore Peak Halliard
8.5.6. Pendants
8.5.7. Vangs
8.5.8. Boom
8.5.9. Topping Lift
8.5.10. Boom Sheets
8.5.11. Main Sail Sheet & Tackle
8.5.12. Guy Pendant Tackle
8.5.13. Foot Rope
8.5.14. Fore Lower Yard
8.5.15. Lifts - Lower Fore Yard
8.5.16. Fore Top Yard
8.5.17. Lifts - Fore Top Yard
8.5.18. Halliard - Fore Top Yard
8.5.19. Sheets
8.5.20. Brace Pendants
8.5.21. Brace Falls
8.5.22. Clew lines
8.5.23. Top Yard Braces
8.5.24. Traveller Out haul/In Haul & Tackle
8.5.25. Flag
9.0. Finishing Touches
