Application of Higher-Strength Hull Structural Thick Steel Plates in Container Carriers/Применение толстых стальных листов в конструкциях корпусов контейнеровозов повышенной прочности

Издание на английском языке
The book explores the development of technologies and materials used in the construction of modern container ships, emphasizing the importance of using thick steel plates with high strength to ensure the necessary rigidity of the ship's hull. In recent decades, with the increasing size of container ships, there has been a need for stronger and more reliable structures, which has led to the use of steel plates with a minimum compressive strength of 460 N/mm2 and steel that prevents brittle cracks.
The author examines how these innovations affect the design of key structural elements, such as the upper deck and longitudinal elements, and discusses the experience and methods used in the shipbuilding industry. The book also includes updated requirements and recommendations based on ship classification rules, and provides additional guidance for the use of high-strength steels, which improves the reliability and safety of container ships.
The publication reflects the latest changes in the regulatory framework and introduces new standards that help take into account the impact of various factors, such as fluctuations and dynamic loads, on the strength and durability of ships. Ultimately, the book serves as an important resource for professionals in the field of shipbuilding and design, striving to introduce modern technologies and ensure high efficiency of marine cargo transportation.
